| 917804 |
Corner Bar Rear Bumper |
1 |
|
 |
|
|
0 |
| HU805 |
Hex Head Setscrew 5/16" UNF X 5/8" |
4 |
|
|
|
|
1 |
| WP8 |
Plain Light Washer ID 5/16" OD 0.69" |
4 |
|
|
|
|
1 |
| WQ308 |
Square Section Lock Washer - 5/16" ID x 0.484" OD x 0.078" Thick |
4 |
|
|
|
|
1 |
| HN2008 |
Plain Nut 5/16" UNF 1/2" AF 0.270"/0.260" Nom Thickness |
4 |
|
|
|
|
1 |
| 917807 |
Centre Bar Rear Bumper |
1 |
□ Up to T20000LD
|
|
|
|
0 |
| 920054 |
Rear Bumper Centre Bar |
1 |
□ From T20000LD
|
|
|
|
0 |
| 713623 |
Overrider Assembly Buffer |
2 |
|
|
|
|
0 |
| 812223 |
Shell Overrider LH |
1 |
|
|
|
|
0 |
| 812224 |
Shell Overrider RH |
1 |
|
|
|
|
0 |
| 502577 |
Plain Washer |
4 |
|
|
|
|
0 |
| 502450 |
Screw |
4 |
|
|
|
|
0 |
| CB6924 |
Carriage Bolt - size unknown |
2 |
|
|
|
|
1 |
| 608491 |
Moulding Buffer PVC |
4 |
□ See ZKC2771 for alternative
|
|
|
|
0 |
| ZKC2771 |
Rubber Seal |
2 |
□ See 608491 for alternative
|
|
|
|
0 |
| 822609 |
Plinth Rear Bumper |
1 |
|
|
|
|
0 |
| WL205 |
Washer - Lock No. 10 0.32" O/D |
2 |
|
|
|
|
1 |
| 627564 |
Nameplate |
1 |
|
|
|
|
0 |
| 822610 |
Plinth Stud |
2 |
|
|
|
|
0 |
| WM5 |
Washer - Plain - Medium - Size Unknown |
2 |
|
|
|
|
1 |
| 517061 |
Bolt |
2 |
|
|
|
|
0 |
| HN2008 |
Plain Nut 5/16" UNF 1/2" AF 0.270"/0.260" Nom Thickness |
2 |
|
|
|
|
1 |
| HB924 |
Hex Head Bolt 3/8" UNF x 3" |
2 |
|
 |
|
|
1 |
| WL209 |
Spring Washer ID 3/8" OD 0.68" |
2 |
|
|
|
|
1 |
| WP9 |
Plain Light Washer ID 3/8" OD 0.81" |
2 |
|
|
|
|
1 |
| 615829 |
Rubber Washer |
2 |
|
|
|
|
0 |
| WP136 |
Plain Light Washer 3/8" ID x 1" OD |
2 |
|
|
|
|
1 |
| HN2009 |
Hex Nut 3/8" UNF x 9/16" AF 0.330/0.320 Thk |
2 |
|
|
|
|
1 |
| WP136 |
Plain Light Washer 3/8" ID x 1" OD |
2 |
|
|
|
|
1 |
| WQ309 |
Spring Washer - Square Section - 3/8"ID x 0.578"OD x 0.093 Thick |
2 |
|
|
|
|
1 |
| 631190 |
Washer Rubber Bumpers |
2 |
|
|
|
|
0 |
| 502450 |
Screw |
2 |
|
|
|
|
0 |
| WP9 |
Plain Light Washer ID 3/8" OD 0.81" |
2 |
|
|
|
|
1 |
| WL209 |
Spring Washer ID 3/8" OD 0.68" |
2 |
|
|
|
|
1 |
| 577165 |
Spacer Front and Rear Bumper |
2 |
|
|
|
|
0 |
| HB920 |
Hex Head Bolt 3/8" UNF x 2 1/2" |
2 |
|
 |
|
|
1 |
| 621514 |
Rear Bumper Bracket |
2 |
|
|
|
|
0 |
| WP136 |
Plain Light Washer 3/8" ID x 1" OD |
2 |
|
|
|
|
1 |
| WQ309 |
Spring Washer - Square Section - 3/8"ID x 0.578"OD x 0.093 Thick |
2 |
|
|
|
|
1 |
| 917803 |
Corner Bar Rear Bumper |
1 |
|
|
|
|
0 |
