| 218542 |
Water Pump Cover |
1 |
□ Caution: The correct type of Pump Cover Has to be Used for 6 and 12 Vaned Pumps. They are Different shapes. Incorrect Fitment may cause severe Engine Damage.
□ Missing from Parts Book Index. |
 |
|
|
0 |
| RTC2255 |
Water Pump Assembly |
1 |
□ Missing from Parts Book Index. |
|
|
|
0 |
| HB811 |
Hex Head Bolt 5/16" UNF x 1 3/8" |
1 |
|
 |
|
|
1 |
| HU806 |
Hex Head Setscrew 5/16" UNF x 3/4" |
2 |
|
|
|
|
1 |
| WP8 |
Plain Light Washer ID 5/16" OD 0.69" |
2 |
|
|
|
|
1 |
| 217707 |
Water Pump Inlet Cover |
1 |
□ Caution: The correct type of Pump Cover Has to be Used for 6 and 12 Vaned Pumps. They are Different shapes. Incorrect Fitment may cause severe Engine Damage.
|
|
|
|
0 |
| 217993 |
Water Cover Pump |
1 |
□ Caution: The correct type of Pump Cover Has to be Used for 6 and 12 Vaned Pumps. They are Different shapes. Incorrect Fitment may cause severe Engine Damage.
|
|
|
|
0 |
| 145017 |
Water Pump Cover Gasket 0.010" Thick |
1 |
□ Must Be Used in Combination to Achieve Correct Pump Clearance as Stated in the ROM
|
|
|
|
0 |
| 149852 |
Water Pump Cover Gasket 0.020" Thick |
1 |
□ Must Be Used in Combination to Achieve Correct Pump Clearance as Stated in the ROM
|
|
|
|
0 |
| 149853 |
Water Pump Cover Gasket 0.030" Thick |
1 |
□ Must Be Used in Combination to Achieve Correct Pump Clearance as Stated in the ROM
|
|
|
|
0 |
| 149095 |
Retaining Bolt |
1 |
□ Caution Left Hand Thread!
|
|
|
|
0 |
| WP9 |
Plain Light Washer ID 3/8" OD 0.81" |
1 |
|
|
|
|
1 |
| 148322 |
Seal |
1 |
|
|
|
|
0 |
| 148462 |
Thrower |
1 |
|
|
|
|
0 |
| 148501 |
Oil Seal |
1 |
|
|
|
|
0 |
| 148178 |
Circlip |
1 |
|
|
|
|
0 |
| 148172 |
Bearing |
1 |
|
|
|
|
0 |
| 147266 |
Oil Thrower |
1 |
|
|
|
|
0 |
| 149760 |
Water Pump Spindle 'O' ring |
1 |
|
|
|
|
0 |
| 149482 |
Waterpump Spindle |
1 |
|
|
|
|
0 |
| 148454 |
Bearing and Seal Housing |
1 |
|
|
|
|
0 |
| 148170 |
Bearing Housing 'O' Ring |
1 |
|
|
|
|
0 |
| 148169 |
Bearing Housing 'O' Ring |
1 |
|
|
|
|
0 |
| 519343 |
Water Pump Assembly |
1 |
|
|
|
|
0 |
Next Page: 02-21
