519579/D - 02-18 |
Next Page: 02-19
| Part Number | Description | Quantity | Additional Notes | Photo | Left or Right Hand Steering | Left or Right Hand | Appears in Stanpart Hardware Cat? |
|---|---|---|---|---|---|---|---|
| 145861 | Oil Seal - 'O' Ring Oil Pump to Block | 1 |  |
0 | |||
| 157348 | Oil Pump Gasket | 1 | |
0 | |||
| 144764 | Oil Pump Drive Shaft | 1 | |
0 | |||
| 147458 | Suction Pipe Gasket | 1 | |
0 | |||
| 149385 | Oil Suction Pipe Assembly | 1 | |
0 | |||
| HB709 | Bolt 1/4" UNF x 1 1/8" | 2 | □ Oil Pickup to Block |
 |
1 | ||
| WP23 | Plain Washer - Light 1/4" ID x 1/2" OD | 2 | □ Oil Pickup to Block |
|
1 | ||
| HB817 | Hex Head Bolt 5/16" UNF x 2 1/8" | 4 | □ Oil Pump to Block |
 |
1 | ||
| WL208 | Spring Washer ID 5/16" OD 0.58" | 4 | □ Oil Pump to Block |
|
1 | ||
| 517721 | Oil Pump Seal - Oil Pump Body to Oil Pump Cover | 1 | |
0 | |||
| 517723 | Oil Pump Shaft and Rotor Assembly | 1 | |
0 | |||
| 517720 | Retaining Screw - Oil Pump Cover to Oil Pump Body | 2 | |
0 | |||
| 517719 | Split Pin | 1 | □ Retains Oil Pump Pressure Release Valve End Plug 152161 |
|
0 | ||
| 517722 | Oil Pump Pressure release Valve End Plug 'O' Ring | 1 | |
0 | |||
| 152161 | Oil Pump Pressure release Valve End Plug | 1 | □ Welding half a Washer to the end of the Plug in a 'D' Shape Will assist With the removal of the Pressure Release Valve assembly without having to remove the pump from the block. |
|
0 | ||
| 215573 | Oil Pump Assembly | 1 | |
0 | |||
| 152157 | Oil Pump Pressure Release Valve Plunger | 1 | |
0 | |||
| 156378 | Oil Pump Pressure Release Valve Spring | 1 | □ Currently available Oil Pumps have stronger springs that cause excessive Oil Pressure. General Thinking suggests re-using an old Spring from an original Stag Pump. (Feb 2011) |
|
0 |
| Notes |
|---|
| No notes found for this page |
