| 143845 |
Engine Block Rear Oil Seal Housing Gasket |
1 |
|
 |
|
|
0 |
| HU706 |
Hexhead Set Screw 1/4" UNF x 3/4" |
4 |
|
|
|
|
1 |
| WL207 |
Spring Washer ID 1/4" OD 0.58" |
4 |
|
|
|
|
1 |
| HU707 |
Hexhead Set Screw 1/4" UNF x 7/8" |
2 |
|
|
|
|
1 |
| 143148 |
Oil Seal |
1 |
|
|
|
|
0 |
| 143149 |
Oil Seal Housing Assembly |
1 |
|
|
|
|
0 |
| HB812 |
Hex Head Bolt 5/16" UNF x 1 1/2" |
1 |
|
 |
|
|
1 |
| WL208 |
Spring Washer ID 5/16" OD 0.58" |
1 |
|
|
|
|
1 |
| WP129 |
Plain Washer - Light 5/16" ID x 3/4" OD |
2 |
|
|
|
|
1 |
| HN2008 |
Plain Nut 5/16" UNF 1/2" AF 0.270"/0.260" Nom Thickness |
2 |
|
|
|
|
1 |
| 214580 |
Oil Sump Gasket |
1 |
|
|
|
|
0 |
| HB812 |
Hex Head Bolt 5/16" UNF x 1 1/2" |
1 |
|
|
|
|
1 |
| WL208 |
Spring Washer ID 5/16" OD 0.58" |
1 |
|
|
|
|
1 |
| WP129 |
Plain Washer - Light 5/16" ID x 3/4" OD |
2 |
|
|
|
|
1 |
| HN2008 |
Plain Nut 5/16" UNF 1/2" AF 0.270"/0.260" Nom Thickness |
2 |
|
|
|
|
1 |
| 214574 |
Oil Sump Assembly |
1 |
|
|
|
|
0 |
| WL208 |
Spring Washer ID 5/16" OD 0.58" |
4 |
|
|
|
|
1 |
| HU857 |
Hex Head Setscrew 5/16" UNC x 7/8" |
2 |
|
|
|
|
1 |
| MA805 |
Hexhead Set Screw sems (Spring Washer) 5/16" UNF x 5/8" |
19 |
|
|
|
|
1 |
| HU908 |
Hexhead Set Screw 3/8" UNF x 1" |
2 |
|
|
|
|
1 |
| 157227 |
Clutch Housing Anchor Bracket |
2 |
|
|
|
|
0 |
| WL209 |
Spring Washer ID 3/8" OD 0.68" |
2 |
|
|
|
|
1 |
| WM59 |
Plain Washer - Medium 3/8" ID x 1.50" x 0.134" OD |
2 |
|
|
|
|
1 |
| HN2009 |
Hex Nut 3/8" UNF x 9/16" AF 0.330/0.320 Thk |
2 |
|
|
|
|
1 |
| 157228 |
Clutch Housing Extension Sump Strap |
2 |
|
|
|
|
0 |
